LASER PLATE CUTTING

Main Configuration
Laser source Raycus/Maxphotonics
Laser head BOCI/ Raytools
Power 3000W-60000W
Servo motor INOVANCE
Software CYPCUT and TUBEPRO
Minimum Cutting area (Width*Length) 1500*3000 mm
Maximum Cutting area (Width*Length) 3500*14000 mm
Racks and pinions/Guide rail GERMERNY LEITESEN/T-WIN/DTX
Electrical Device AMERICA HONEYWELL
COMPUTER WINDOWS 10
Cooling chiller TONGFEI
Reducer TECHMECH
FAN 15KW
Automatic lubrication system YES
Voltage Three phase, 380V 50HZ
Maximum Acceleration Speed 1.5G
Maximum Speed 180m/min
Cutting type Straight cutting
Computer CPU core i5, SSD, window 10 license
Display Vertical 21-inch Display
Stabilizer Include
Controller Cabinet with Air conditional Include

Description

Key Features

  • Equipped with high-quality laser source from leading global brands, with warranty and service centers in Thailand.
  • Offers fiber laser power options ranging from 3000W to 60,000W.
  • Capable of cutting thick materials such as steel (0–80 mm) and stainless steel (0–65 mm).
  • Supports direct import of cutting formats or CAD files, enabling precise cutting of complex workpieces (*DXF, *AI, *PLT, etc.).
  • Available with both single table and exchange table designs to meet high-volume, fast-paced industrial cutting demands.
  • Built with a durable, modern design using high-standard manufacturing processes, ensuring long-term operational stability.
  • High cutting speed with excellent accuracy, user-friendly operation, durable performance, and compliant with international standards.
  • Handles large and heavy workpieces with low maintenance costs.
  • Installation and training provided by experienced laser engineers, with after-sales consultation and technical support.
  • Authorized distributor of spare parts and accessories for laser cutting machines.
